Atomos Shogun Classic 7" HDR Monitor-Recorder-Switcher

Atomos Shogun Classic 7" HDR Monitor-Recorder-Switcher - image 2

Atomos Shogun Classic 7" HDR Monitor-Recorder-Switcher - image 3

Atomos Shogun Classic 7" HDR Monitor-Recorder-Switcher · 4x SDI · ISO Rec · 3000 nits

Name: Atomos Shogun Classic 7" HDR Monitor-Recorder-Switcher · 4x SDI · ISO Rec · 3000 nits
Brand: Atomos
SKU: ATOMSHG701
Price: 49000.0 THB
Availability: OutOfStock

Sold out

49,000 ฿ - 49,000 ฿

49,000 ฿

49,000 ฿ - 49,000 ฿

49,000 ฿

Availability:

Out of stock

SKU ATOMSHG701

Manufacturer warranty

Genuine products. Returns or exchanges due to a change of mind are not accepted. Contact us promptly if your item is damaged or you receive an incorrect item.

Delivery

Thailand delivery is ฿100, or free for orders of ฿5,000 or more. Final delivery options and charges are shown at checkout. Contact our team for the delivery timing of your items.

Warranty & after-sales support

Warranty follows the manufacturer’s or distributor’s policy. Returns or exchanges due to a change of mind are not accepted. Box contents follow the manufacturer’s list; please check the details for your model before ordering. Contact us promptly if your item is damaged or you receive an incorrect item.

Atomos Shogun Classic 7" HDR Monitor-Recorder-Switcher — Monitor, Recorder and Switcher in One Unit

The Atomos Shogun Classic combines a 3000 nits HDR monitor, a 4K recorder and a 4-camera switcher in one unit. It accepts 4 x SDI inputs, switches live on the touchscreen, and can record separate ISO files from every camera at the same time. It suits cinema, commercials, events and live broadcast work (ATOMSHG701).

Key Features

7-inch (7.2") 1920 x 1200 touchscreen, up to 3000 nits brightness, 1,000,000:1 contrast, 10-bit HDR/SDR display
4 x SDI inputs, usable as a Multicam switcher with Quad-view, and records 4 channels of 1080p60 ISO at the same time
Records 4K DCI / UHD video up to 60 frames per second from both HDMI and SDI
Supports Apple ProRes RAW, ProRes (HQ / 422 / LT), Avid DNxHR and DNxHD
Records 2K slow motion up to 240p
Records to 2.5-inch SSDs via the Master Caddy II
HDMI 2.0 and 12G-SDI input/output with built-in HDMI ⇄ SDI conversion
Supports balanced XLR audio with 48V Phantom power (via XLR Breakout cable, sold separately)
Supports 3D LUTs (.cube) and Dolby Vision over HDMI
Complete monitoring tools: False Color, Focus Peaking, Waveform, Vectorscope, RGB Parade, Zebra, Anamorphic De-squeeze

Best For

Cinema and commercial shoots
Live broadcast and multi-camera events (Live Multicam)
Interviews and studio work that need separate ISO files from every camera
Videographers who want to upgrade file quality from mirrorless cameras

Specifications

Model	Atomos Shogun Classic (ATOMSHG701)
Screen Size	7.2-inch Capacitive Touchscreen
Resolution	1920 x 1200
Brightness	Up to 3000 nits
Contrast	1,000,000:1 (Dynamic AtomHDR)
Video Input	1 x HDMI 2.0, 4 x SDI (12G / 6G / 3G / Quad-link)
Video Output	1 x HDMI 2.0, 1 x 12G-SDI
Recording	4K DCI / UHD up to 60p, 2K up to 240p, ProRes RAW up to 5.7K (depending on camera model)
Codec	Apple ProRes RAW, ProRes HQ / 422 / LT, Avid DNxHR / DNxHD (.MOV)
ISO Recording	4 x 1080p60 simultaneously
Media	2.5-inch SSD via Master Caddy II
Audio	Embedded HDMI / SDI, XLR Balanced 48V (via Breakout Cable), 3.5mm headphone jack
LUT	3D LUT (.cube)
Sync	BNC Sync Port, supports Atomos UltraSync One
Battery	NP-F Series and locking DC power

In the Box

Atomos Shogun Classic x 1
Travel Case x 1
Master Caddy II Drive Caddy x 1
DC Locking Connector x 1

FAQ

Q: Can I use it with mirrorless cameras?
A: Yes. It works with any camera that outputs HDMI 2.0 or SDI, from mirrorless to cinema cameras.
Q: Can it really be used as a live switcher?
A: Yes. Connect up to 4 cameras via SDI, switch live on the touchscreen, and record separate ISO files for every camera along with XML for importing into editing software.
Q: Is an XLR cable included?
A: No. You need the XLR Breakout Cable, which is sold separately.

Atomos Shogun Classic — monitor, record and switch, all in one unit
